Applications:
Online water quality monitoring for pollution sources, industrial wastewater, water environment quality monitoring, drinking water supply and safety assurance, ecological supervision, etc.
Product Features:
• New photoelectric quantitative technology不受色度大、悬浮物多、气泡多等干扰的影响 (Note: I'll translate fully) – Unaffected by high chromaticity, high suspended solids, numerous bubbles, and other interferences, offering high reliability and precision, with strong anti-interference capability.
• High detection accuracy, low measurement下限 (lower limit), and small long-term drift of the instrument.
• One-key self-test function and self-diagnosis function.
• Single-channel high-integration valve manifold, making maintenance and cleaning simple and fast.
• All-weather networking function, allowing remote monitoring of instrument status anytime, anywhere.
• Alarm function, quality control function, and remote control function.
• Automatic cleaning function and automatic calibration function.
• On-the-hour measurement, interval measurement, and externally controlled measurement.
• Automatically resumes operation after power failure recovery.
• Automatic alert and auto-reset function for malfunctions and reagent (sample) shortage.
• Fault logging function.
• Capable of storing historical data for more than 3 years.
Calibration cycle: Arbitrarily specified time
Calibration cycle: Arbitrarily specified time
Maintenance cycle: ≥720h/time
Maintenance workload: <2 hours/month
Signal output: RS485/RS232/USB interface, standard 2 channels 4-20mA output, standard 2 channels digital input/output
Voltage stability: ≤±5%
Insulation resistance: ≥20MΩ
MTBF: ≥1440h/time
Display output: Equipped with 7-inch color LCD touch screen
Data storage: Can store 3 years of measurement data, data can be stored cyclically
Data export: Measurement values can be exported to a USB flash drive via USB port
Environmental requirements: Indoor with controllable temperature, recommended temperature (5-28°C), humidity ≤90% (non-condensing)
Power supply and consumption: (220V±22)V/AC, (50±0.5Hz), 5A, 150W
Instrument dimensions: 1350*450*300 (mm)
Instrument weight: Approx. 20kg
