Supports Bluetooth configuration for more convenient operation.
Non-contact measurement, suitable for various installation scenarios. Calculates flow rate combined with cross-section parameters, unaffected by wind, temperature, fog, haze, sediment, floating matter on water surface, etc.
Low power consumption, compact size, high reliability, and easy maintenance.
Automatically filters environmental interference to ensure stable and reliable data.
Intelligent flow algorithm supports multiple channel configurations, calculating flow rate based on the velocity-area method.
Bidirectional flow identification with configurable filtering.
Supports flow rate calibration, allowing adjustment according to the actual flow velocity of the installation site.
Transmit power, sensitivity and other parameters can be adjusted according to actual requirements to suit different installation environments.
Power-off protection: in case of sudden power failure, data is automatically saved without loss.
Housing made of aluminum alloy, with an overall IP67 protection rating, ensuring stable operation under various environmental conditions.
Supply voltage: DC 12V
Flow velocity parameters: Measuring range: 0.1~20m/s, Accuracy: ±0.01m/s, Resolution: 0.01m/s, Antenna beam angle: 12°, Flow direction identification: Bidirectional automatic identification, configurable filtering
Water level parameters: Measuring range: 0.15~40m, Accuracy: ±0.005m, Resolution: 0.001m, Antenna beam angle: 14°
Flow rate parameters: Instantaneous flow: 0.001~999999.999 m³/s, Total flow: 0.01~999999999999999999 m³
Power consumption: ≤140mA/12V
Radar frequency: Flow velocity band: 24GHz, Water level band: 80GHz
Communication method: RS485 (Modbus-RTU)
Baud rate: 115200bps (adjustable)
Operating environment: Operating temperature: -45°C ~ 85°C; Humidity: 95% RH non-condensing
Protection rating: IP67
Enclosure material: Aluminum alloy
Total weight: 800g
Dimensions (mm): 159.5 × 95 × 66
