Outdoor Water Monitor

The outdoor multi-parameter online water quality monitor is specially designed for real-time water quality monitoring. It can continuously and automatically measure and analyze various physical, chemical and biological parameters of water bodies.
The device integrates multiple water quality monitoring parameters into a single unit, realizing centralized data display and management through a touch screen human-machine interface. It integrates online water quality analysis, remote data transmission, database management and automatic control into one system, greatly improving operational convenience for various water quality monitoring applications.
Combined with modern sensor technology, automatic control technology and IoT communication technology, the equipment forms a complete integrated water quality monitoring system. It supports real-time, continuous and automatic online monitoring, fully replacing the traditional manual sampling and laboratory analysis mode. It effectively solves the pain points of delayed data feedback and high labor costs in water quality monitoring.

INTRODUCTION

SPECIFICATIONS

Application:
Online water quality monitoring for tap water, surface water, groundwater, source water, drinking water,
river water, watercourses, marine water, sewage discharge outlets, aquaculture,
and secondary water supply scenarios.
Product Features:
One system supports measurement of multiple water quality parameters.
Optional measuring parameters with high accuracy and excellent repeatability.
Sensors can be freely combined, featuring easy installation and low maintenance.
No reagent dosing and no reagent consumption.
No secondary pollution and no waste liquid discharge.
Automatic electrode compensation within a certain range.
Multiple output options available: 4…20mA, RS485, MODBUS-RTU, GPRS and Ethernet port.
Supports connection via 4G wireless network, WiFi and Ethernet.
Real-time remote monitoring by PC and inquiry via mobile APP.
Built-in remote control functions to realize linked operation of on-site devices.

Model	HT-1105E
Display	10-inch color touch screen
Communication Interface	RS485
Power Supply	220V AC (12-24V DC optional)
Power Consumption	< 50W
Operating Environment	Temperature: (0-50) ℃;
Storage Environment	Relative Humidity: ≤85% RH (non-condensing)
Enclosure Dimensions	1400mm × 650mm × 450mm (H × W × D)
