Applications:
Online water quality monitoring for different water bodies such as tap water, surface water, groundwater, source water, drinking water, river water, river channels, oceans, sewage discharge outlets, aquaculture, secondary water supply, etc.
Product Features:
1. Color touch screen design, user-friendly HMI, simple operation, direct concentration reading;
2. Uses digestion colorimetric integrated tube, making the water sample measurement process simple, fast, safe, and accurate;
3. Large data storage capacity, power-off protection design ensures instrument is not damaged and data never lost;
4. 1-point to 7-point calibration mode, automatically calculates slope, intercept and correlation coefficient, high measurement accuracy;
5. Intelligent fault self-diagnosis design, making instrument management and maintenance simple and convenient;
6. Strong anti-interference capability, suitable for industrial field use;
7. Uses semiconductor cold light source emitter, light source life up to tens of thousands of hours;
8. Can connect to a computer to export measurement data; built-in printer for printing measurement data and historical records;
9. Low reagent consumption, low operating cost, strong anti-interference capability;
10. Wide measurement range, diverse measurement parameters; parameters can be freely combined according to user requirements;
11. Pre-stored standard measurement curves, easily retrievable for measurement; simultaneously allows user-defined measurement curves.
Measurement parameters: COD, ammonia nitrogen, total phosphorus, total nitrogen, etc. (freely combinable according to user requirements);
Display: Color LCD touch screen with Chinese operation interface;
Colorimetry method: Colorimetric tube (digestion and colorimetry integrated tube)
Number of curves: 100 measurement curve parameters can be set;
Calibration mode: 1-7 point calibration mode with automatic curve value correction;
Data storage: Can store 30,000 measurement results, data never lost after power failure;
Printing: Built-in thermal printer;
Data communication: RS232 + USB interface, allows uploading measurement results to a computer for statistical analysis by the user;
Ambient temperature: (5 ~ 40) ℃; Ambient humidity: Relative humidity < 85% (non-condensing);
Dimensions: 300*220*120mm;
Power supply: AC220V±10% / 50Hz;
Weight: 2.8kg;
